Ray-Vac

The Ray-Vac automatic pool cleaner is designed to both vacuum and sweep your swimming pool.

Ray-Vac and Ray-Vac Desert Models

The Ray-Vac automatic pool cleaner is designed to both vacuum and sweep your swimming pool. The cleaner head moves in a random submerged pattern about the pool, traveling, vacuuming and cleaning from the pool floor to the water line.

  • The Ray-Vac automatic pool cleaner is designed to both vacuum and sweep your swimming pool.
  • The cleaner head moves in a random submerged pattern about the pool, traveling, vacuuming and cleaning from the pool floor to the water line.

Models

Models Description
2827 Jandy Ray-Vac Retail Model (White) w/Speed Adjustment Kit
2880 Jandy Ray-Vac Builder Model (White), Gunite
2956 Jandy Ray-Vac Builder Model H&H (White, Long)
3195 Jandy Ray-Vac Builder Model (Black)
3310 Jandy Ray-Vac H&H Ray-Vac Builder (Black, Long)
3376 Jandy Ray-Vac Builder Model (White), V/F
3397 Jandy Ray-Vac Retail Model (White w/Speed Adjmnt. Kit), V/F
3647 Jandy Ray-Vac Retail Model (Black) w/Speed Adjustment Kit, Gunite
6766 Jandy Ray-Vac Builder Model (White) w/Corner Kit
7000 Jandy Ray-Vac Builder Desert Model (White Only) w/Corner Kit
7101 Jandy Ray-Vac Builder Desert Model (White)

Parts Breakout Diagram

Automatic Pool Cleaners

Ray-Vac Parts List

Launch our online catalog viewer to review breakout diagrams and part numbers.

Learn More

Frequently Asked Questions

Click a frequently asked question below to see the answer.

Cleaner stops moving.

Cause: Filter system off. Unit in backup cycle. Dirty Finger Screen or Energy Filter. Hole in hose. Backup Hydro-Timer releasing most of the water out of the discharge hole. Transporter jet plugged.

Solution: Check time clock. Normal operation. Clean Finger Screen or Energy Filter. Replace defective hose. Replace defective backup jet gear assembly. Clean or replace the transporter jet.

Pool cleaner stalls in corner.

Cause: Corner restricting movement of Ray-Vac. Nose caster wheel jammed with debris. Increase backup.

Solution: No adjustment needed. Wait until backup jet pulls unit out of the corner. Clean or replace. See instructions under speed adjustment.

Pool cleaner stalls in skimmer.

Cause: Skimmer opening is larger than Ray-Vac. Increase backup.

Solution: No adjustment needed. Wait until backup jet pulls unit out of corner. Add optional skimmer guard. See instructions under speed adjustment.

Resources

Ray-Vac Owner's Manual

Item #: H05551
File Size: 591991
Language: EN

Download View Online

Ray-Vac Installation Manual

Item #: H05550
File Size: 0
Language: EN

Download View Online

Ray-Vac Quick Disconnect Replacement Kit

Item #: H0554900
File Size: 352632
Language: EN

Download View Online

Ray-Vac® Hydro-Timer Replacement Kit

Item #: H0554700
File Size: 295039
Language: EN

Download View Online
